CCNPv8 ENCOR (Version 8.0) – Chapters 6 – 7: Routing Essentials and EIGRP Exam Answers 2021

1. Which type of routing protocol uses LSAs and TLVs to support extended features?

   • link-state
   • hybrid
   • distance vector
   • path vector


     Answers Explanation & Hints: Link-state routing protocols include capabilities such as LSAs for OSPF and TLVs (type/length/value) for IS-IS that allow them to support extended features.

2. What are two characteristics of link-state routing protocols? (Choose two.)

   • They use more CPU and memory resources than distance vector protocols do.
   • They provide routers with a synchronized identical map of the network.
   • They use path attributes to determine the best loop-free path.
   • They periodically send full routing table updates to directly connected neighbors.
   • They can load balance across unequal metric cost paths.


     Answers Explanation & Hints: Link-state protocols like OSPF and ISIS use more CPU and memory resources than distance vector protocols do because they maintain a complete synchronized map of the network and run the SPF algorithm to determine the best path.

3. What data is used by OSPF and ISIS for loop prevention?

   • a synchronized map of the network
   • hop count to the destination
   • autonomous system path to the destination
   • feasible distance calculation to the destination


     Answers Explanation & Hints: OSPF and ISIS are link-state routing protocols. As link-state routing protocols they have a synchronized and identical map of the network. Using the complete map of the network, every router in the network then runs the Dijkstra shortest path first (SPF) algorithm to calculate the best shortest loop-free paths.

4. Which routing protocol incorporates characteristics of both distance vector and link-state protocols?

   • EIGRP
   • ISIS
   • iBGP
   • EBGP


     Answers Explanation & Hints: As a hybrid routing protocol, EIGRP incorporates the characteristics of both distance vector and link-state protocols. It uses bandwidth and other metrics rather than hop count to determine the best path and this information is advertised to all neighbors.

5. How do EIGRP routers establish and maintain neighbor relationships?

   • by exchanging neighbor tables with directly attached routers
   • by comparing known routes to information received in updates
   • by exchanging hello packets with neighboring routers
   • by dynamically learning new routes from neighbors
   • by exchanging routing tables with directly attached routers


     Answers Explanation & Hints: EIGRP uses hello messages to establish and maintain neighbor relationships.

6. A router has installed several routes into the routing table. How will the router determine which route to use to forward packets?

   • the longest prefix match
   • the highest metric
   • the lowest metric
   • the lowest administrative distance


     Answers Explanation & Hints: The route chosen for forwarding a packet is the route with the longest prefix length matching the destination network of the packet. The metric and administrative distance are used to determine which routes will appear in the routing table.

7. What is the effect of configuring the ipv6 unicast-routing command on a router?

   • to assign the router to the all-nodes multicast group
   • to enable the router as an IPv6 router
   • to permit only unicast packets on the router
   • to prevent the router from joining the all-routers multicast group


     Answers Explanation & Hints: When the ipv6 unicast-routing command is implemented on a router, it enables the router as an IPv6 router. Use of this command also assigns the router to the all-routers multicast group.

8. Why would a floating static route be configured with an administrative distance that is higher than the administrative distance of a dynamic routing protocol that is running on the same router?

   • to be used as a backup route
   • to load-balance the traffic
   • to act as a gateway of last resort
   • to be the priority route in the routing table


     Answers Explanation & Hints: By default, dynamic routing protocols have a higher administrative distance than static routes. Configuring a static route with a higher administrative distance than that of the dynamic routing protocol will result in the dynamic route being used instead of the static route. However, should the dynamically learned route fail, then the static route will be used as a backup.

9. Which static route statement shows a recursive IPv6 static route?

   • ipv6 route 0::/0 S0/0/0
   • ipv6 route 0::/0 S0/0/0 254
   • ipv6 route 2001:db8:cafe:1::/56 S0/0/0
   • ipv6 route 2001:db8:cafe:1::/56 2001:db8:1000:10::1
   • ipv6 route 2001:db8:cafe:1::/56 S0/0/0 2001:db8:1000:10::1


     Answers Explanation & Hints: In a recursive static route, only the next-hop IPv6 address is specified. As a consequence, the router must perform a recursive route table lookup to find an exit interface associated with the network of the IPv6 address.

10. Refer to the exhibit. Which command will properly configure an IPv6 static route on R2 that will allow traffic from PC2 to reach PC1 without any recursive lookups by router R2?



    • R2(config)# ipv6 route 2001:db8:10:12::/64 2001:db8:32::1
    • R2(config)# ipv6 route 2001:db8:10:12::/64 S0/0/0
    • R2(config)# ipv6 route ::/0 2001:db8:32::1
    • R2(config)# ipv6 route 2001:db8:10:12::/64 S0/0/1


      Answers Explanation & Hints: A nonrecursive route must have an exit interface specified from which the destination network can be reached. In this example 2001:db8:10:12::/64 is the destination network and R2 will use exit interface S0/0/0 to reach that network. Therefore, the static route would be ipv6 route 2001:db8:10:12::/64 S0/0/0.

11. Refer to the exhibit. Router R1 has an OSPF neighbor relationship with the ISP router over the 192.168.0.32 network. The 192.168.0.36 network link should serve as a backup when the OSPF link goes down. The floating static route command ip route 0.0.0.0 0.0.0.0 S0/0/1 100 was issued on R1 and now traffic is using the backup link even when the OSPF link is up and functioning. Which change should be made to the static route command so that traffic will only use the OSPF link when it is up?​



    • Add the next hop neighbor address of 192.168.0.36.
    • Change the administrative distance to 1.
    • Change the destination network to 192.168.0.34.
    • Change the administrative distance to 120.


      Answers Explanation & Hints: The problem with the current floating static route is that the administrative distance is set too low. The administrative distance will need to be higher than that of OSPF, which is 110, so that the router will only use the OSPF link when it is up.

12. What is used by BGP to guarantee a loop free path to reach a destination?

    • a record of each autonomous system that a routing advertisement has traversed
    • a distance calculation based on cumulative delay and minimum bandwidth
    • the count of router hops to reach a destination
    • the cumulative cost as measured in bandwidth


      Answers Explanation & Hints: BGP is a path vector protocol which uses several path attributes to determine the best path. To prevent loops BGP updates include a record of each autonomous system that the routing advertisement traversed. A BGP router that receives the update should not see its own AS in the AS Path. If it did, it would indicate a loop.

13. What is the purpose for creating VRFs on a router?

    • to isolate paths
    • to prevent routing loops
    • to determine the vector to reach a destination network
    • to keep a record of all autonomous systems that routing advertisements have traversed


      Answers Explanation & Hints: Virtual routing and forwarding, or VRF, is a technology that creates several separate virtual routers on a single physical router. Each of the virtual routers acts as an independent and separate router so that their paths are isolated from each other.

14. Which technology creates segmentation between network interfaces, IP addresses, and routing tables?

    • virtual routing and forwarding
    • virtual LANs
    • multiprotocol label switching
    • virtual router redundancy protocol


      Answers Explanation & Hints: Virtual routing and forwarding, or VRF, is a technology that creates several separate virtual routers on a single physical router. Each of the virtual routers acts as an independent and separate router so that their paths are isolated from each other.

15. What is the administrative distance of an IS-IS route?

    • 115
    • 170
    • 110
    • 90

16. What is the administrative distance of an internal EIGRP route?

    • 90
    • 110
    • 115
    • 20

17. What is the administrative distance of an external EIGRP route?

    • 170
    • 200
    • 115
    • 110

18. What is the administrative distance of an external EIGRP route?

    • 170
    • 115
    • 110
    • 90

19. What is the administrative distance of an IS-IS route?

    • 115
    • 1
    • 5
    • 0

20. What is the administrative distance of a static route?

    • 1
    • 5
    • 20
    • 0

21. What is the administrative distance of a static route?

    • 1
    • 110
    • 90
    • 115

22. What is the administrative distance of an EIGRP summary route?

    • 5
    • 20
    • 90
    • 110

23. What is the administrative distance of an OSPF route?

    • 110
    • 115
    • 170
    • 90

24. What is the administrative distance of a directly connected interface?

    • 0
    • 1
    • 5
    • 20

25. Refer to the exhibit. R2 has two possible paths to the 192.168.10.4 network. What would make the alternate route meet the feasibility condition?



    • a reported distance less than 3523840
    • a reported distance greater than 41024000
    • a feasible distance greater than 41024000
    • an administrative distance less than 170


      Answers Explanation & Hints: To meet the feasibility condition, the reported distance (RD) to a network must be less than the current feasible distance to the same destination network. In this example the current feasible distance is 3523840. This means that to be a feasible successor, a route would need a reported distance less than 3523840.

26. Which protocol number is used to indicate that an EIGRP packet is encapsulated in an IP packet?

    • 6
    • 17
    • 88
    • 89


      Answers Explanation & Hints: In an IP packet header, the field protocol number indicates which protocol is used in the encapsulated PDU. 6 is TCP, 17 is UDP, 88 is EIGRP, and 89 is OSPF.

27. Match the description to the EIGRP packet type. (Not all options are used.)



    Answers Explanation & Hints: EIGRP uses five different packet types include: Hello packets – Used for neighbor discovery and to maintain neighbor adjacencies. Update packets – Used to propagate routing information to EIGRP neighbors. Acknowledgment packets – Used to acknowledge the receipt of an EIGRP message that was sent using reliable delivery. Query packets – Used to query routes from neighbors. Reply packets – Sent in response to an EIGRP query.

28. Which statement describes the autonomous system number used in EIGRP configuration on a Cisco router?

    • It carries the geographical information of the organization.
    • It functions as a process ID in the operation of the router.
    • It is a globally unique autonomous system number that is assigned by IANA.
    • It identifies the ISP that provides the connection to network of the organization.


      Answers Explanation & Hints: The autonomous system number used in the EIGRP configuration is not associated with the Internet Assigned Numbers Authority (IANA) globally assigned autonomous system numbers that are used by external routing protocols. It just functions as a process ID, which is necessary because a router may run multiple instances of EIGRP. Each instance of EIGRP can be configured to support and exchange routing updates for different networks. An organization has the freedom to choose its own AS number in the EIGRP configuration.

29. Which bandwidth value is used when calculating the EIGRP metric of a route?

    • the fastest bandwidth of all interfaces on the router
    • the slowest bandwidth of all interfaces on the router
    • the fastest bandwidth of all outgoing interfaces between the source and destination
    • the slowest bandwidth of all outgoing interfaces between the source and destination


      Answers Explanation & Hints: The bandwidth factor that is used to calculate the composite metric of the EIGRP is defined as the slowest bandwidth of all outgoing interfaces between the source and destination.

30. Refer to the exhibit. All the routers that are displayed are part of the EIGRP domain. Assuming EIGRP metric weights are not altered in the configurations, which path will a packet take that originates from a host on the 192.168.1.0/24 network and is going to a host on the 192.168.2.0/24 network?



    • R1, R4, R3
    • R1, R5, R3
    • R1, R2, R3
    • R1, R2, R5, R3


      Answers Explanation & Hints: EIGRP only uses the slowest bandwidth in its composite metric. The slowest bandwidth in the path R1, R2, R5, R3 is 64 kb/s and thus offers the best path to the 192.168.2.0/24 network.

31. Which two metric weights are set to one by default when costs in EIGRP are being calculated? (Choose two.)

    • k1
    • k2
    • k3
    • k4
    • k5
    • k6


      Answers Explanation & Hints: By default, k1 and k3 are set to one and k2, k4, and k5 are set to zero during cost calculation by the EIGRP process. There is no k6 value.

32. Which routing protocol supports load balancing across links with unequal costs?

    • OSPFv2
    • EIGRP
    • RIPv2
    • OSPFv3


      Answers Explanation & Hints: Routing protocols with two or more paths to a destination network can load balance traffic across multiple paths. EIGRP is the only routing protocol that supports load balancing across unequal cost paths.

33. How has the EIGRP routing protocol improved by having interface delay measured in picoseconds instead of microseconds?

    • It speeds up convergence.
    • It allows for a larger number of networks.
    • It provides better metrics for high speed interfaces.
    • It improves performance and communication time between directly connected neighbor routers.


      Answers Explanation & Hints: The original values used to calculate EIGRP metrics were in microseconds for delay and kilobytes per second for bandwidth. When using EIGRP wide metrics, the delay units are picoseconds and within the formula, the metric is found by multiplying by 65,535 instead of 256, thus providing support of interface bandwidth up to 655 terabits per second.

34. If all router Ethernet interfaces in an EIGRP network are configured with the default EIGRP timers, how long will a router wait by default to receive an EIGRP packet from its neighbor before declaring the neighbor unreachable?

    • 10 seconds
    • 15 seconds
    • 20 seconds
    • 30 seconds


      Answers Explanation & Hints: EIGRP uses the hold time as the maximum time it should wait for receiving a hello packet (or other EIGRP packets) from its neighbor before declaring that the neighbor is unreachable. By default the hold time is 3 times greater than the hello interval. On LAN interfaces, the default hello time is 5 seconds and the default hold time is 15 seconds.

35. What two conditions will result in an EIGRP route going into the active state? (Choose two.)

    • One neighbor has not met the feasibility condition.
    • The router is not sending queries.
    • The successor is down.
    • There is no feasible successor.
    • The network has been recalculated.


      Answers Explanation & Hints: If a successor is no longer available, and there is no feasible successor, an EIGRP route will be put into the active state while the router actively searches for a new path to the destination.

36. An EIGRP router loses the route to a network. Its topology table contains two feasible successors to the same network. What action will the router take?

    • The DUAL algorithm is recomputed to find an alternate route.
    • The router uses the default route.
    • The best alternative backup route is immediately inserted into the routing table.
    • The router will query neighbors for an alternate route.


      Answers Explanation & Hints: Because EIGRP uses the DUAL algorithm, the router is able to maintain information on all potential loop-free backup routes. In the event of the failure of a routing table entry, the router immediately inserts the best backup route into the routing table.

37. Which feature of the EIGRP routing protocol can provide fast re-convergence without DUAL recomputation in the event of a route failure?

    • having a successor route
    • having a feasible successor route
    • having a route in the passive state
    • having a route in the active state


      Answers Explanation & Hints: EIGRP avoids DUAL recomputation of routes whenever possible by maintaining a list of backup routes (feasible successors) in the topology table already determined to be loop-free. If the primary route (the successor route, which is in the passive state) in the routing table fails, the best backup route is immediately added to the routing table. A route in the active state is in the process of being recomputed by DUAL.

38. What are two benefits of applying summarization to networks within a company that uses the EIGRP routing protocol? (Choose two.)

    • reduced size of routing tables
    • reduced number of Layer 3 switches required
    • reduced number of routers that must maintain a neighbor adjacency
    • reduced number of hops the packet must travel throughout the network
    • reduced impact when a route goes active


      Answers Explanation & Hints: When summarization is applied within any routing protocol, the routing tables within the organization are smaller. An added benefit to EIGRP-enabled routers is that when a route goes active during convergence or when a link has gone down and there is no feasible successor, the number of routers that receive query packets is reduced.

39. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the reported distance of the successor route for 172.18.3.0/24?

    • 28160
    • 2172416
    • 2684416
    • 2072316

40. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the reported distance of the feasible successor route for 192.168.24.0/24?

    • 2342912
    • 2854912
    • 2072316
    • 227692

41. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the reported distance of the feasible successor route for 192.168.24.0/24?

    • 2342912
    • 3072
    • 2937
    • 2495120

42. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the reported distance of the successor route for 10.34.1.0/24?

    • 2937
    • 2495120
    • 3072
    • 227692

43. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the metric for the successor route for 172.18.5.0/24?

    • 2495120
    • 227692
    • 2854912
    • 3072

44. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the metric for the successor route for 172.18.5.0/24?

    • 2495120
    • 5376
    • 2937
    • 3072

45. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the metric for the feasible successor route for 10.34.1.0/24?

    • 5376
    • 2937
    • 3072
    • 2495120

46. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the metric for the successor route for 10.34.1.0/24?

    • 3072
    • 2937
    • 2495120
    • 227692

47. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the metric for the successor route for 172.18.3.0/24?

    • 2172416
    • 2684416
    • 2072316
    • 2342912

48. Refer to a portion of an EIGRP topology table:

    P 172.18.3.0/24, 1 successors, __ is 2172416
    via 172.18.4.3 (2172416/28160), Serial0/0/1
    P 172.18.5.0/24, 1 successors, __ is 2495120
    via 172.18.6.3 (2495120/227692), Serial0/1/0
    P 192.168.24.0/24, 1 successors, __ is 2684416
    via 192.168.13.5 (2684416/2072316), Serial0/0/0
    via 172.18.4.3 (2854912/2342912), Serial0/0/1
    P 10.34.1.0/24, 1 successors, __ is 3072
    via 10.13.1.3 (3072/2937), GigabitEthernet0/1
    via 10.14.1.4 (5376/2937), GigabitEthernet0/2

    What is the feasible distance of the 172.18.5.0/24 route?

    • 2495120
    • 2854912
    • 2342912
    • 227692
