Network Security (Version 1) – Network Security 1.0 Modules 18-19: VPNs Group Exam Answers 2021

  1. Which protocol creates a virtual point-to-point connection to tunnel unencrypted traffic between Cisco routers from a variety of protocols?

    • OSPF
    • IPsec
    • IKE
    • GRE
      Answers Explanation & Hints:

      Generic Routing Encapsulation (GRE) is a tunneling protocol developed by Cisco that encapsulates multiprotocol traffic between remote Cisco routers. GRE does not encrypt data. OSPF is a open source routing protocol. IPsec is a suite of protocols that allow for the exchange of information that can be encrypted and verified. Internet Key Exchange (IKE) is a key management standard used with IPsec.

  2. Which is a requirement of a site-to-site VPN?

    • It requires a client/server architecture.
    • It requires the placement of a VPN server at the edge of the company network.
    • It requires hosts to use VPN client software to encapsulate traffic.
    • It requires a VPN gateway at each end of the tunnel to encrypt and decrypt traffic.
      Answers Explanation & Hints:

      Site-to-site VPNs are static and are used to connect entire networks. Hosts have no knowledge of the VPN and send TCP/IP traffic to VPN gateways. The VPN gateway is responsible for encapsulating the traffic and forwarding it through the VPN tunnel to a peer gateway at the other end which decapsulates the traffic.

  3. Which two statements describe a remote access VPN? (Choose two.)

    • It connects entire networks to each other.
    • It requires hosts to send TCP/IP traffic through a VPN gateway.
    • It is used to connect individual hosts securely to a company network over the Internet.
    • It may require VPN client software on hosts.
    • It requires static configuration of the VPN tunnel.
      Answers Explanation & Hints:

      Remote access VPNs can be used to support the needs of telecommuters and mobile users by allowing them to connect securely to company networks over the Internet. To connect hosts to the VPN server on the corporate network, the remote access VPN tunnel is dynamically built by client software that runs on the hosts.

  4. Two corporations have just completed a merger. The network engineer has been asked to connect the two corporate networks without the expense of leased lines. Which solution would be the most cost effective method of providing a proper and secure connection between the two corporate networks?

    • Cisco AnyConnect Secure Mobility Client with SSL
    • Cisco Secure Mobility Clientless SSL VPN
    • Frame Relay
    • remote access VPN using IPsec
    • site-to-site VPN
      Answers Explanation & Hints:

      The site-to-site VPN is an extension of a classic WAN network that provides a static interconnection of entire networks. Frame Relay would be a better choice than leased lines, but would be more expensive than implementing site-to-site VPNs. The other options refer to remote access VPNs which are better suited for connecting users to the corporate network versus interconnecting two or more networks.

  5. Which two scenarios are examples of remote access VPNs? (Choose two.)

    • A toy manufacturer has a permanent VPN connection to one of its parts suppliers.
    • All users at a large branch office can access company resources through a single VPN connection.
    • A mobile sales agent is connecting to the company network via the Internet connection at a hotel.
    • A small branch office with three employees has a Cisco ASA that is used to create a VPN connection to the HQ.
    • An employee who is working from home uses VPN client software on a laptop in order to connect to the company network.
      Answers Explanation & Hints:

      Remote access VPNs connect individual users to another network via a VPN client that is installed on the user device. Site-to-site VPNs are “always on” connections that use VPN gateways to connect two sites together. Users at each site can access the network on the other site without having to use any special clients or configurations on their individual devices.

  6. Which statement describes the effect of key length in deterring an attacker from hacking through an encryption key?

    • The length of a key will not vary between encryption algorithms.
    • The length of a key does not affect the degree of security.
    • The shorter the key, the harder it is to break.
    • The longer the key, the more key possibilities exist.
      Answers Explanation & Hints:

      While preventing brute-force attacks and other forced decryption concerns, the longer the key length, the harder it is to break. A 64-bit key can take one year to break with a sophisticated computer, while a 128-bit key may take 10 19 years to decrypt. Different encryption algorithms will provide varying key lengths for implementation.

  7. Which statement accurately describes a characteristic of IPsec?

    • IPsec works at the application layer and protects all application data.
    • IPsec works at the transport layer and protects data at the network layer.
    • IPsec is a framework of open standards that relies on existing algorithms.
    • IPsec is a framework of proprietary standards that depend on Cisco specific algorithms.
    • IPsec is a framework of standards developed by Cisco that relies on OSI algorithms.
      Answers Explanation & Hints:

      IPsec can secure a path between two network devices. IPsec can provide the following security functions:
      Confidentiality – IPsec ensures confidentiality by using encryption.
      Integrity – IPsec ensures that data arrives unchanged at the destination using a hash algorithm, such as MD5 or SHA.
      Authentication – IPsec uses Internet Key Exchange (IKE) to authenticate users and devices that can carry out communication independently. IKE uses several types of authentication, including username and password, one-time password, biometrics, pre-shared keys (PSKs), and digital certificates.
      Secure key exchange – IPsec uses the Diffie-Hellman (DH) algorithm to provide a public key exchange method for two peers to establish a shared secret key.

  8. How is “tunneling” accomplished in a VPN?

    • New headers from one or more VPN protocols encapsulate the original packets.
    • All packets between two hosts are assigned to a single physical medium to ensure that the packets are kept private.
    • Packets are disguised to look like other types of traffic so that they will be ignored by potential attackers.
    • A dedicated circuit is established between the source and destination devices for the duration of the connection.
      Answers Explanation & Hints:

      Packets in a VPN are encapsulated with the headers from one or more VPN protocols before being sent across the third party network. This is referred to as “tunneling”. These outer headers can be used to route the packets, authenticate the source, and prevent unauthorized users from reading the contents of the packets.

  9. How is “tunneling” accomplished in a VPN?

    • New headers from one or more VPN protocols encapsulate the original packets.
    • All packets between two hosts are assigned to a single physical medium to ensure that the packets are kept private.
    • Packets are disguised to look like other types of traffic so that they will be ignored by potential attackers.
    • A dedicated circuit is established between the source and destination devices for the duration of the connection.
      Answers Explanation & Hints:

      The two primary protocols used with IPsec are AH and ESP. AH is protocol number 51 and provides data authentication and integrity for IP packets that are exchanged between the peers. ESP, which is protocol number 50, performs packet encryption.

  10. What technology is used to negotiate security associations and calculate shared keys for an IPsec VPN tunnel?

    • 3DES
    • IKE
    • PSK
    • SHA
      Answers Explanation & Hints:

      The Internet Key Exchange (IKE) protocol is a key management protocol standard used when creating an IPsec VPN tunnel. IKE negotiates security associations (SAs) and calculates shared keys.​

  11. What are the two modes used in IKE Phase 1? (Choose two.)

    • aggressive
    • main
    • passive
    • primary
    • secondary
      Answers Explanation & Hints:

      The two modes for IKE Phase 1 are main and aggressive. Main mode takes more time because the identity of the IKE peers are hidden from eavesdroppers.

  12. What takes place during IKE Phase 2 when establishing an IPsec VPN?

    • IPsec security associations are exchanged.
    • Traffic is exchanged between IPsec peers.
    • ISAKMP security associations are exchanged.
    • Interesting traffic is identified.
      Answers Explanation & Hints:

      During IKE Phase 2, IPsec peers exchange the IPsec security associations (SAs) that each peer is willing to use to establish the IPsec tunnel.

  13. What is a function of the GRE protocol?

    • to configure the set of encryption and hashing algorithms that will be used to transform the data sent through the IPsec tunnel
    • to encapsulate multiple OSI Layer 3 protocol packet types inside an IP tunnel
    • to configure the IPsec tunnel lifetime
    • to provide encryption through the IPsec tunnel​
      Answers Explanation & Hints:

      The transform set is the set of encryption and hashing algorithms that will be used to transform the data sent through the IPsec tunnel. GRE supports multiprotocol tunneling. It can encapsulate multiple OSI Layer 3 protocol packet types inside an IP tunnel. Routing protocols that are used across the tunnel enable dynamic exchange of routing information in the virtual network. GRE does not provide encryption.​

  14. A site-to-site IPsec VPN is to be configured. Place the configuration steps in order.

    Network Security (Version 1) - Network Security 1.0 Modules 18-19 VPNs Group Exam Answers 001
    Network Security (Version 1) – Network Security 1.0 Modules 18-19 VPNs Group Exam Answers 001
  15. What type of traffic is supported by IPsec?

    • IPsec supports all traffic permitted through an ACL.
    • IPsec only supports unicast traffic.
    • IPsec supports all IPv4 traffic.
    • IPsec supports layer 2 multicast traffic.
      Answers Explanation & Hints:

      IPsec only supports unicast traffic. If multicast traffic needs to travel through a tunnel, a GRE tunnel will need to be configured between the peers.

  16. Refer to the exhibit. What HMAC algorithm is being used to provide data integrity?

    Network Security (Version 1) - Network Security 1.0 Modules 18-19 VPNs Group Exam Answers 01
    Network Security (Version 1) – Network Security 1.0 Modules 18-19 VPNs Group Exam Answers 01
    • SHA
    • MD5
    • DH
    • AES
      Answers Explanation & Hints:

      Two popular algorithms that are used to ensure that data is not intercepted and modified (data integrity) are MD5 and SHA. The command Router1(config-isakmp)# hash sha indicates that SHA is being used. AES is an encryption protocol and provides data confidentiality. DH (Diffie-Hellman) is an algorithm that is used for key exchange. RSA is an algorithm used for authentication.

  17. Refer to the exhibit. A VPN tunnel is configured on the WAN between R1 and R2. On which R1 interface(s) would a crypto map be applied in order to create a VPN between R1 and R2?

    Network Security (Version 1) - Network Security 1.0 Modules 18-19 VPNs Group Exam Answers 02
    Network Security (Version 1) – Network Security 1.0 Modules 18-19 VPNs Group Exam Answers 02
    • G0/0
    • G0/0 and G0/1
    • S0/0/0
    • all R1 interfaces
      Answers Explanation & Hints:

      The crypto map command is used to finish creating the IPsec security policy by doing the followingbinding the interesting traffic ACL and transform set to the crypto map
      specifying the IP address of the remote VPN site
      configuring the Diffie-Hellman group
      configuring the IPsec tunnel lifetime
      The crypto map is bound to the S0/0/0 R1 interface.​

  18. Router R1 has configured ISAKMP policies numbered 1, 5, 9, and 203. Router R2 only has default policies. How will R1 attempt to negotiate the IKE Phase 1 ISAKMP tunnel with R2?

    • R1 and R2 cannot match policies because the policy numbers are different.
    • R1 will attempt to match policy #1 with the most secure matching policy on R2.
    • R1 will begin to try to match policy #1 with policy #65514 on R2.
    • R1 will try to match policy #203 with the most secure default policy on R2.
      Answers Explanation & Hints:

      Peers will attempt to negotiate using the policy with the lowest number (highest priority). Peers do not require matching priority numbers. R1 will attempt to use the most secure default policy (policy #1). If R2 has a matching policy, then R1 and R2 can successfully negotiate the IKE Phase 1 ISAKMP tunnel. If there is no agreement to use the most secure default policy, R1 will attempt to use the next most secure policy.

  19. Consider the following configuration on a Cisco ASA:

    crypto ipsec transform-set ESP-DES-SHA esp-des esp-sha-hmac

    What is the purpose of this command?

    • to define only the allowed encryption algorithms
    • to define the ISAKMP parameters that are used to establish the tunnel
    • to define what traffic is allowed through and protected by the tunnel
    • to define the encryption and integrity algorithms that are used to build the IPsec tunnel
      Answers Explanation & Hints:

      The transform set is negotiated during Phase 2 of the IPsec VPN connection process. The purpose of the transform set is to define what encryption and authentication schemes can be used. The device doing the VPN initiation offers the acceptable transform sets in order of preference, in this case, ESP authentication using DES for encryption or ESP authentication using SHA-HMAC authentication and integrity for the data payload. Remember that ESP provides confidentiality with encryption and integrity with authentication. The ESP-DES-SHA is the name of the transform set. The parameters that follow (esp-des and esp-sha-hmac) are the specific types of encryption or authentication that is supported by the ASA for the VPN tunnel that uses this transform set.

  20. What is needed to define interesting traffic in the creation of an IPsec tunnel?

    • access list
    • security associations
    • transform set
    • hashing algorithm
      Answers Explanation & Hints:

      In order to bring up an IPsec tunnel, an access list must be configured with a permit statement that will identify interesting traffic. Once interesting traffic is detected by matching the access list, the tunnel security associations can be negotiated.​

  21. When the CLI is used to configure an ISR for a site-to-site VPN connection, what is the purpose of the crypto map command in interface configuration mode?

    • to bind the interface to the ISAKMP policy
    • to configure the transform set
    • to force IKE Phase 1 negotiations to begin
    • to negotiate the SA policy
      Answers Explanation & Hints:

      The crypto map command, along with the name of the policy, is used to bind the interface to the ISAKMP policy created previously. A transform set is configured using the crypto ipsec transform-set command. Interesting traffic between peers forces IKE Phase 1 negotiations to begin. Peers negotiate the ISAKMP SA policy in step 2 of IPsec negotiations.

  22. Refer to the exhibit. What show command displays whether the securityk9 software is installed on the router and whether the EULA license has been activated?

    Network Security (Version 1) - Network Security 1.0 Modules 18-19 VPNs Group Exam Answers 03
    Network Security (Version 1) – Network Security 1.0 Modules 18-19 VPNs Group Exam Answers 03
    • show running-config
    • show version
    • show interfaces s0/0/0
    • show crypto isakmp policy 1
      Answers Explanation & Hints:

      The show version command displays the status of technology packages on the router. Based on the partial output shown, the router software already includes ipbasek9 and securityk9. The EvalRightToUse parameter shows that the license is active thereby giving access to the cryptographic features, IPsec and ISAKMP, required to create an IPsec VPN.

  23. Which two statements describe the IPsec protocol framework? (Choose two.)

    • AH provides integrity and authentication.
    • AH provides both authentication and encryption.
    • ESP uses UDP protocol 51.
    • AH provides encryption and integrity.
    • AH uses IP protocol 51.
